Main Particulars
Length Overall
49.89 M
Breadth mld.
09.14 M
Depth mld.
03.96 M
Draught Loaded
2.50 M
Gross Tonnage
640
Net Tonnage
564
Compliment
8 crew + 2 Off
Speed
8 Kn.
Capacities
Cargo
750 KL / 640 MT
Fuel Oil
30.0 T
Fresh Water
30.0 T
Classification
RINA Class IV vessel
Main Engines
2 x 400 BHP Caterpillar Diesel engines
Gear Boxes
2 x ZF make hydraulic reverse reduction boxes.
Generators
2 x 30 KVA Ashok Leyland make Diesel Gen. sets.
Cargo Pumps
2 x 100 M^3/hr gear pumps driven off independent diesel engines.
Cargo Tanks
6 Nos.
SALIENT FEATURES
- Double Skin construction
- Totally clean cargo tanks.
- Flat Deck
- Can carry 2 grades of cargoes with double segregation in the pipe line.
- Gear pumps which can pump up to 380 CST products and pumping capacity of 2 x 125 M^3/hr at a head of 25.0 M.
- Independent discharge and loading manifolds on Port & Stbd. Sides.
- Fitted with approved type Drip Sampler and flow meter.
- Fully classed with RINA Class as a Tanker Barge with Restricted Load line.
- Electro hydraulic steering gear.
- Electrically operated remote control for the main engines & gear boxes.
- Electro hydraulic anchor windlass.
