IMO No. 8693047
Main Particulars
Length Overall
56.90M
Breadth mld.
12.00 M
Depth mld.
4.00 M
Draught Loaded
2.50 M
Gross Tonnage
733.00 T
Net Tonnage
229.00 T
Compliment
9 crew + 2 Off
Speed
8 Kn.
Capacities
Cargo
1000 KL / 850 MT
Fuel Oil
30.0 T
Fresh Water
40.0 T
Classification
Indian River Sea Veessel Type 2 - IRS Class OIL TANKER ZONE I for Carriage of Liquid having flash Point above 60° with Restricted Loadline
Main Engines
2 x 325 BHP NT 855 M Cummins Diesel engines
Gear Boxes
2 x ZF make hydraulic reverse reduction boxes.
Generators
2 x 30 KVA
Cargo Pumps
2 x 150 M^3/hr gear pumps driven off Diesel Engine 72BHP each
Cargo Tanks
8 Nos.
SALIENT FEATURES
- Double Skin construction
- Totally clean cargo tanks.
- Flat Deck
- Can carry 2 grades of cargoes with double segregation in the pipe line.
- Gear pumps which can pump up to 380 CST products and pumping capacity of 2 x 150 M^3/hr at a head of 25.0 M.
- Independent discharge and loading manifolds on Port & Stbd. Sides.
- Fitted with approved type Drip Sampler and flow meter.
- Fully classed with IRS as a Oil Tanker with Restricted Load line.
- Electro hydraulic steering gear.
- Electrically operated remote control for the main engines & gear boxes.
- Electro hydraulic anchor windlass.
- Heating coils to heat the cargo upto 55 degrees C
