Main Particulars

Year of Built


Draught Loaded

2.50 Meter


8 Kn.

Gross Tonnage

740 T

Net Tonnage

292 T



1000 KL / 850 MT

Fuel Oil

30.0 T

Fresh Water

40.0 T


IRS IWL OIL TANKER ZONE I for Carriage of Liquid having flash Point above 60° with Restricted Loadline

Main Engines

2 x 325 BHP NT 855 M Cummins Diesel engines

Gear Boxes

2 x ZF make hydraulic reverse reduction boxes.


2 x 30 KVA

Cargo Pumps

2 x 150 M^3/hr gear pumps driven off Diesel Engine 72BHP each

Cargo Tanks

8 Nos.


  • Flat Deck
  • Can carry 2 grades of cargoes with double segregation in the pipe line.
  • Gear pumps which can pump up to 380 CST products with pumping capacity of 2 x 150 M^3/hr at a head of 25.0 Meter.
  • Independent discharge and loading manifolds on Port & Stbd
  • Fitted with approved type Drip Sampler and flow meter
  • Fully classed with IRS as a Tanker Barge with Restricted Load line.
  • Electro hydraulic steering gear.
  • Electrically operated remote control for the main engines & gear boxes.
  • Electro hydraulic anchor windlass.
