Main Particulars
Length Overall
57.50 M
Breadth mld.
12.00 M
Depth mld.
4.00 M
Draught Loaded
2.50 M
Gross Tonnage
734.00 T
Net Tonnage
285.00 T
Compliment
8 crew + 2 Off
Speed
8 Kn.
Capacities
Cargo
1200 KL / 1000 MT
Fuel Oil
40.0 T
Fresh Water
45.0 T
Classification
IRS IWL OIL TANKER ZONE I for Carriage of Liquid having flash Point above 60^ with Restricted Loadline
Main Engines
2 x 325 BHP NT 855 M Cummins Diesel engines
Gear Boxes
2 x ZF 325
Generators
2 x 100 KVA
Cargo Pumps
2 x 150 M^3/hr gear pumps driven off Electrical Motors 75BHP
Cargo Tanks
8 Nos.
SALIENT FEATURES
- Double Skin construction
- Totally clean cargo tanks.
- Flat Deck
- Can carry 2 grades of cargoes with double segregation in the pipe line.
- Gear pumps which can pump up to 380 CST products and pumping capacity of 2 x 150 M^3/hr at a head of 25.0 M.
- Independent discharge and loading manifolds on Port & Stbd. Sides.
- Fitted with approved type Drip Sampler and flow meter.
- Fully classed with IRS as a Tanker Barge with Restricted Load line.
- Electro hydraulic steering gear.
- Electrically operated remote control for the main engines & gear boxes.
- Electro hydraulic anchor windlass.
